Balanceo de carga en EIGRP

eigrp

Al igual que otros IGP, EIGRP permite el balanceo de carga cuando conoce la misma red por varios vecinos, y esta posee el mismo costo en todas estas. Esto es conocido como enrutamiento equal-cost multipath (ECMP, o enrutamiento de múltiples rutas del mismo costo).

Por defecto, en plataformas IOS vienen habilitadas un máximo de 4 rutas para hacer balanceo de carga (se permiten tener 4 rutas del mismo costo), la cual puede aumentar hasta un máximo de 32 ECMP por prefijos (redes).

La topología a usar para validar esto, es la siguiente:

eigrp01

Lo primero que hacemos es configurar EIGRP en cada router.

R1:

R1(config)#router eigrp 12345
R1(config-router)#no auto-summary
R1(config-router)#net 192.168.12.1 0.0.0.0
R1(config-router)#net 192.168.13.1 0.0.0.0
R1(config-router)#net 192.168.14.1 0.0.0.0

R2:

R2(config)#router eigrp 12345
R2(config-router)#no auto-summary
R2(config-router)#net 192.168.12.2 0.0.0.0
R2(config-router)#
*Jan 5 21:28:21.359: %DUAL-5-NBRCHANGE: EIGRP-IPv4 12345: Neighbor 192.168.12.1 (FastEthernet0/0) is up: new adjacency
R2(config-router)#net 192.168.25.2 0.0.0.0

R3:

R3(config)#router eigrp 12345
R3(config-router)#no auto-summary
R3(config-router)#net 192.168.13.2 0.0.0.0
R3(config-router)#
*Jan 5 21:29:28.123: %DUAL-5-NBRCHANGE: EIGRP-IPv4 12345: Neighbor 192.168.13.1 (FastEthernet0/0) is up: new adjacency
R3(config-router)#net 192.168.35.2 0.0.0.0

R4:

R4(config)#router eigrp 12345
R4(config-router)#no auto-summary
R4(config-router)#net 192.168.14.2 0.0.0.0
R4(config-router)#
*Jan 5 21:30:22.955: %DUAL-5-NBRCHANGE: EIGRP-IPv4 12345: Neighbor 192.168.14.1 (Serial1/1) is up: new adjacency
R4(config-router)#net 192.168.45.2 0.0.0.0

R5:

R5(config)#router eigrp 12345
R5(config-router)#no auto-summary
R5(config-router)#net 192.168.25.1 0.0.0.0
R5(config-router)#
*Jan 5 21:31:31.967: %DUAL-5-NBRCHANGE: EIGRP-IPv4 12345: Neighbor 192.168.25.2 (Serial1/0) is up: new adjacency
R5(config-router)#net 192.168.35.1 0.0.0.0
R5(config-router)#
*Jan 5 21:31:38.219: %DUAL-5-NBRCHANGE: EIGRP-IPv4 12345: Neighbor 192.168.35.2 (Serial1/1) is up: new adjacency
R5(config-router)#net 192.168.45.1 0.0.0.0
R5(config-router)#
*Jan 5 21:31:45.663: %DUAL-5-NBRCHANGE: EIGRP-IPv4 12345: Neighbor 192.168.45.2 (Serial1/2) is up: new adjacency
R5(config-router)#net 5.5.5.5 0.0.0.0

Como se comentó, por defecto las plataformas que usan IOS tienen configurados un máximo de 4 ECMP:

R1#sh ip protocols
*** IP Routing is NSF aware ***

Routing Protocol is "eigrp 12345"
  Outgoing update filter list for all interfaces is not set
  Incoming update filter list for all interfaces is not set
  Default networks flagged in outgoing updates
  Default networks accepted from incoming updates
  EIGRP-IPv4 Protocol for AS(12345)
    Metric weight K1=1, K2=0, K3=1, K4=0, K5=0
    NSF-aware route hold timer is 240
    Router-ID: 192.168.14.1
    Topology : 0 (base)
      Active Timer: 3 min
      Distance: internal 90 external 170
      Maximum path: 4
      Maximum hopcount 100
      Maximum metric variance 1

  Automatic Summarization: disabled
  Maximum path: 4
  Routing for Networks:
    192.168.12.1/32
    192.168.13.1/32
    192.168.14.1/32
  Routing Information Sources:
    Gateway         Distance      Last Update
    192.168.14.2          90      00:10:39
    192.168.12.2          90      00:10:39
    192.168.13.2          90      00:10:39
  Distance: internal 90 external 170

Para poder modificar este valor, es necesario utilizar el comando maximum-paths en la configuración de EIGRP:

R1(config)#router eigrp 12345
R1(config-router)#maximum-paths ?
  <1-32>  Number of paths

R1(config-router)#maximum-paths 10
R1(config-router)#do sh ip pro
*** IP Routing is NSF aware ***

Routing Protocol is "eigrp 12345"
  Outgoing update filter list for all interfaces is not set
  Incoming update filter list for all interfaces is not set
  Default networks flagged in outgoing updates
  Default networks accepted from incoming updates
  EIGRP-IPv4 Protocol for AS(12345)
    Metric weight K1=1, K2=0, K3=1, K4=0, K5=0
    NSF-aware route hold timer is 240
    Router-ID: 192.168.14.1
    Topology : 0 (base)
      Active Timer: 3 min
      Distance: internal 90 external 170
      Maximum path: 10
      Maximum hopcount 100
      Maximum metric variance 1

  Automatic Summarization: disabled
  Maximum path: 10
  Routing for Networks:
    192.168.12.1/32
    192.168.13.1/32
    192.168.14.1/32
  Routing Information Sources:
    Gateway         Distance      Last Update
    192.168.14.2          90      00:00:07
    192.168.12.2          90      00:00:07
    192.168.13.2          90      00:00:07
  Distance: internal 90 external 170

Por lo tanto, el máximo de rutas de igual costo que se pueden instalar en la RIB (Routing Information Base, o tabla de enrutamiento), se puede modificar, llegando hasta un máximo de 32.

En esta topología, se tienen dos rutas con el mismo costo:

R1#sh ip ro eigrp
Codes: L - local, C - connected, S - static, R - RIP, M - mobile, B - BGP
       D - EIGRP, EX - EIGRP external, O - OSPF, IA - OSPF inter area
       N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
       E1 - OSPF external type 1, E2 - OSPF external type 2
       i - IS-IS, su - IS-IS summary, L1 - IS-IS level-1, L2 - IS-IS level-2
       ia - IS-IS inter area, * - candidate default, U - per-user static route
       o - ODR, P - periodic downloaded static route, H - NHRP, l - LISP
       + - replicated route, % - next hop override

Gateway of last resort is not set

      5.0.0.0/24 is subnetted, 1 subnets
D        5.5.5.0 [90/2300416] via 192.168.13.2, 00:13:07, FastEthernet2/0
                 [90/2300416] via 192.168.12.2, 00:13:07, FastEthernet0/0
D     192.168.25.0/24 [90/2172416] via 192.168.12.2, 00:13:07, FastEthernet0/0
D     192.168.35.0/24 [90/2172416] via 192.168.13.2, 00:13:07, FastEthernet2/0
D     192.168.45.0/24 [90/2681856] via 192.168.14.2, 00:13:07, Serial1/0

Pero a diferencia de otros protocolos de enrutamiento, EIGRP también soporta balanceo de carga con rutas de costo distinto (unequal-cost multipath, UCMP), permitiendo instalar rutas de los sucesores y los sucesores factibles (FS):

R1#sh ip eigrp topology
EIGRP-IPv4 Topology Table for AS(12345)/ID(192.168.14.1)
Codes: P - Passive, A - Active, U - Update, Q - Query, R - Reply,
       r - reply Status, s - sia Status

P 192.168.25.0/24, 1 successors, FD is 2172416
        via 192.168.12.2 (2172416/2169856), FastEthernet0/0
P 192.168.35.0/24, 1 successors, FD is 2172416
        via 192.168.13.2 (2172416/2169856), FastEthernet2/0
P 192.168.12.0/24, 1 successors, FD is 28160
        via Connected, FastEthernet0/0
P 5.5.5.0/24, 2 successors, FD is 2300416
        via 192.168.12.2 (2300416/2297856), FastEthernet0/0
        via 192.168.13.2 (2300416/2297856), FastEthernet2/0
        via 192.168.14.2 (2809856/2297856), Serial1/0
P 192.168.45.0/24, 1 successors, FD is 2681856
        via 192.168.14.2 (2681856/2169856), Serial1/0
P 192.168.13.0/24, 1 successors, FD is 28160
        via Connected, FastEthernet2/0
P 192.168.14.0/24, 1 successors, FD is 2169856
        via Connected, Serial1/0

Para lograr esto, es necesario modificar el multiplicador variance.

El valor del variance es la multiplicación de la distancia factible (FD) con el multiplicador variance, donde por defecto, el multiplicador variance está configurado en 1.

Entonces, si hacemos el cálculo del valor del variance, quedaría lo siguiente:

2300416 * 1 = 2300416

Lo que significa, que se permite hacer balanceo de carga con rutas que tengan una métrica (FD) de 2300416.

Ahora, si el multiplicador variancia lo cambiamos a 2, podemos incorporar la ruta a través de R4, debido que ahora el valor del variance es:

2300416 * 2 = 4600832

Donde podemos apreciar que la métrica por R4 (2809856) se encuentra dentro del valor del variance.

Para configurar esto, es necesario ir a la configuración de EIGRP:

R1(config)#router eigrp 12345
R1(config-router)#variance ?
  <1-128>  Metric variance multiplier

R1(config-router)#variance 2

Para validar el valor configurado, usamos el comando show ip protocols:

R1#sho ip protocols | in variance
      Maximum metric variance 2

Y si ahora vemos la RIB, podremos ver que se tienen las 3 rutas instaladas:

R1#sh ip ro eigrp
Codes: L - local, C - connected, S - static, R - RIP, M - mobile, B - BGP
       D - EIGRP, EX - EIGRP external, O - OSPF, IA - OSPF inter area
       N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
       E1 - OSPF external type 1, E2 - OSPF external type 2
       i - IS-IS, su - IS-IS summary, L1 - IS-IS level-1, L2 - IS-IS level-2
       ia - IS-IS inter area, * - candidate default, U - per-user static route
       o - ODR, P - periodic downloaded static route, H - NHRP, l - LISP
       + - replicated route, % - next hop override

Gateway of last resort is not set

      5.0.0.0/24 is subnetted, 1 subnets
D        5.5.5.0 [90/2809856] via 192.168.14.2, 00:03:26, Serial1/0
                 [90/2300416] via 192.168.13.2, 00:03:26, FastEthernet2/0
                 [90/2300416] via 192.168.12.2, 00:03:26, FastEthernet0/0
D     192.168.25.0/24 [90/2172416] via 192.168.12.2, 00:03:26, FastEthernet0/0
D     192.168.35.0/24 [90/2172416] via 192.168.13.2, 00:03:26, FastEthernet2/0
D     192.168.45.0/24 [90/2681856] via 192.168.14.2, 00:03:26, Serial1/0

Pero lo que se pueden estar preguntado, una vez configurado el variance, es si el balanceo de carga entre cada ruta es igual (el primer paquete se envía por el vecino 192.168.14.2, luego el segundo por el vecino 192.168.13.2 y el tercer por el vecino 192.168.12.2, y así sucesivamente).

El tema, es que como tenemos rutas con distintos costos, el balanceo de carga que viene configurado por defecto en EIGRP, hace que se envíen más paquetes por los enlaces con mejor métrica que por los enlaces de peor métrica.

Para saber el tipo de balanceo de carga que viene activado por defecto en EIGRP, usamos el siguiente comando:

R1#sh run all | sec router eigrp
router eigrp 12345
 timers active-time 3
 timers graceful-restart purge-time 240
 metric maximum-hops 100
 metric weights 0 1 0 1 0 0
 traffic-share balanced
 maximum-paths 10
 variance 2
 network 192.168.12.1 0.0.0.0
 network 192.168.13.1 0.0.0.0
 network 192.168.14.1 0.0.0.0
 distance eigrp 90 170
 no auto-summary
 no passive-interface default
 eigrp log-neighbor-changes
 eigrp log-neighbor-warnings 10
 eigrp event-log-size 500
 no shutdown

Y si usamos el comando show ip route para ver la red específica aprendida por EIGRP, podemos observar que tiene un parámetro llamado traffic share count:

R1#sh ip ro 5.5.5.0
Routing entry for 5.5.5.0/24
  Known via "eigrp 12345", distance 90, metric 2300416, type internal
  Redistributing via eigrp 12345
  Last update from 192.168.14.2 on Serial1/0, 09:22:56 ago
  Routing Descriptor Blocks:
    192.168.14.2, from 192.168.14.2, 09:22:56 ago, via Serial1/0
      Route metric is 2809856, traffic share count is 49
      Total delay is 45000 microseconds, minimum bandwidth is 1544 Kbit
      Reliability 255/255, minimum MTU 1500 bytes
      Loading 1/255, Hops 2
    192.168.13.2, from 192.168.13.2, 09:22:56 ago, via FastEthernet2/0
      Route metric is 2300416, traffic share count is 60
      Total delay is 25100 microseconds, minimum bandwidth is 1544 Kbit
      Reliability 255/255, minimum MTU 1500 bytes
      Loading 1/255, Hops 2
  * 192.168.12.2, from 192.168.12.2, 09:22:56 ago, via FastEthernet0/0
      Route metric is 2300416, traffic share count is 60
      Total delay is 25100 microseconds, minimum bandwidth is 1544 Kbit
      Reliability 255/255, minimum MTU 1500 bytes
      Loading 1/255, Hops 2

Aquí se especifica que los primeros 49 paquetes serán enviados por el vecino 192.168.14.2, luego los siguientes 60 a través de 192.168.13.2 y los otros 60 a través de 192.168.12.2, y luego se repite lo mismo.

Pero, ¿cómo EIGRP calcula esto?

La respuesta es que, al igual que como calcula su métrica, existe una fórmula matemática para obtener este ratio. A continuación, mostraré sin mucho detalle, cómo se calcula este valor:

La principal fórmula es dividiendo la mejor métrica, con la peor, y luego multiplicándola por 240:

2300416 / 2809856 * 240 = 196.4868804665 ≈ 196

2300416 / 2300416 * 240 = 240

Luego se obtiene el máximo común divisor de estos números, en este caso es 4, y luego estos valores son divididos por el MCD:

196 / 4 = 49

240 / 4 = 60

Por lo tanto, en caso de que tengamos varias rutas con el mismo costo, el valor traffic share count es 1:

R1#sh ip ro 5.5.5.0
Routing entry for 5.5.5.0/24
  Known via "eigrp 12345", distance 90, metric 2300416, type internal
  Redistributing via eigrp 12345
  Last update from 192.168.13.2 on FastEthernet2/0, 00:00:11 ago
  Routing Descriptor Blocks:
  * 192.168.13.2, from 192.168.13.2, 00:00:11 ago, via FastEthernet2/0
      Route metric is 2300416, traffic share count is 1
      Total delay is 25100 microseconds, minimum bandwidth is 1544 Kbit
      Reliability 255/255, minimum MTU 1500 bytes
      Loading 1/255, Hops 2
    192.168.12.2, from 192.168.12.2, 00:00:11 ago, via FastEthernet0/0
      Route metric is 2300416, traffic share count is 1
      Total delay is 25100 microseconds, minimum bandwidth is 1544 Kbit
      Reliability 255/255, minimum MTU 1500 bytes
      Loading 1/255, Hops 2
